Flooding seal is also known as flooding seal ring, flooding seal is only a popular term in the sealing industry, flooding seal can be applied to most harsh conditions, and can adapt to some special medium requirements.
Application range of pan-plug seal:
Used for the sealing effect of reciprocating motion of the inner circumference seal. The floodplug seal can be used in harsh working conditions. The pan-plug seal can also be adapted to the requirements of some special media. It is recommended that you can not crawl when used, shaft and chemical corrosion resistance, suitable for most media applications of the seal ring, such as valves, pumps, separators, brakes, batching devices, etc.
Two, the characteristics and advantages of the pan-plug seal
(1)can be used for reciprocating movement and rotation movement;
(2) Pan-plug seal can be adapted to most liquids and chemicals;
(3) Low friction coefficient, wear resistance and dimensional stability;
(4) It will not crawl when it can be controlled;
(5) Strong corrosion resistance, good dimensional stability;
(6) Able to withstand rapid temperature changes in the environment;
Flood plug seal is an extremely wide range of applications of the sealing ring, is made of a spring with corrosion resistance (generally stainless steel) and a similar to the U-shaped O-shaped filled PTFE seal ring made of material. When the system pressure is zero, RVC flooding seal, spring provides the initial pre-pressure, when the system pressure increases, the U-shaped cavity is full of pressure medium and the lip is close to the cylinder wall, M2 type Tekang flooding seal, so that the seal in the whole process of pressure change, always has a good sealing performance.
It is suitable for both static and static plug sealing. In addition to the above sealing application in high temperature corrosion environment, it is very suitable for the sealing parts of air hydraulic cylinder because of its low friction coefficient of sealing lip, stable sealing contact pressure, high pressure resistance, allowing large radialrun-out and groove size error. Replace U shape or V shape pressing to obtain excellent sealing performance and service life.
Post time: May-24-2023
